Zero sparking; thus no risk of fires/ safety is assured.
Compact and reliable with high power to weight ratio.
Minimal maintenance required.
No complicated air hoses connections.
Fully enclosed motor to prevent dust and dirt from entering climber.
Lower rope wear as there is only one sheave.
Built to withstand adverse environmental conditions.
Built in manual crank descent in case of power failure.
Usage counter installed in each climber to ensure proper maintenance.
Item
Pneumatic Air Motor
Motor Type
Air Motor - Vane type
Power
Compressed Air
Climber Size
340mm x 270mm x 300mm
Weight
< 40KG (As compared to most brands at >48KG)
Lifting Capacity
Up to 500KG Internal load test certificate can be provided.
Wire Rope
8.3mm galvanized steel
Lifting Speed
9m/min
Braking
Two brakes are built into Climber. First brake: Air brake. Secondary brake: Mechanical brake with 1.85 times braking force.
Nominal Power
1.6 HP
Nominal Speed
1250 rpm
Idling Speed
2500 rpm
Air Consumption
1.6m3/min
Hose Internal Diameter
19mm
Exhaust
G 3/4 "
Air Intake
G 1/2"
Max Air Pressure
6 bar
Industries
Oil and gas and shipping where no sparking is compulsory.
With robust construction and eco-friendly features, these TAKAHASHI air-powered gondolas are perfect for navigating complex shipbuilding environments. Reduce operational costs, improve safety protocols, and increase throughput with our advanced air motor solutions. Elevate your shipyard operations today with the power of innovation.
